NEW FOR 2011
* * * * * * APPROVED * * * Glen Ridge Motorsports* * * * * *

* * * APPROVED * * * Albany/Saratoga & Devil's Bowl * * *

GM 350 / 602
CRATE ENGINE


Due to questionable availability of GM's 602 crate engine, Hunt's Machine has a crate engine available that is built to duplicate the GMPP 602 crate engine.

Every engine is balanced, clearances checked and documented, dyno tested, and broken in with Joe Gibb’s Racing break in oil.  You will get a Dyno sheet with your engine that is from you own engine being tested telling you HP, Torque, oil pressure, and jet sizes.

HE-602-350-350....................$3895

(comparable to GM part# 88958602)

Crankshaft: Scat or Eagle nodular iron
Connecting Rods: Scat, Eagle or comparable aftermarket I-beam; w/ARP bolts
Pistons: Hypereutectic dished
Camshaft: Hydraulic flat tappet
        Camshaft lift: .443 intake / .465 exhaust
        Camshaft duration: (@ .050") 214 intake / 224 exhaust
Cylinder Heads: Aftermarket replacement Vortec iron; 64cc chambers
Valve Sizes: 1.94 intake / 1.5 exhaust
Rocker Arms: Stamped steel 1.5:1 ratio, with Crane "Kool Nuts" for extra lubrication
Timing Chain: Roller w/Torrington bearing to prevent block wear
Oil Pan: Circle Track w/baffles and trap doors
Intake Manifold: Aluminum dual plane
Block: Bore & stroke: maximum bore 4.060 / 3.484 stroke


* * * * * Engine Tested and Approved * * * * *
by RPM Racing Engines for CVRA
DYNO Results Match GM 602 Crate Engine


To keep price as low as possible, we will use a used 2 bolt block, cleaned, magnafluxed, bored to a maximum of .060" deck plate honed, line bore checked, surfaced, & new cam bearings and expansion plugs installed.

In addition to every engine being balanced, assembled & valves adjusted, they also include an HEI distributor, Circle Track valve covers, timing cover and balancer.

NOTE: There will be 3 block options available for this package:
               - 4 Bolt main used blot..................................................................................................... $150 additional
               - NEW GM 4 bolt main block*........................................................................................... $600 additional
               - NEW Dart SHP 4 bolt main block w/nodular caps....................................................... $850 additional

There can also be a cost savings if you provide your own block for the build.

To avoid tampering, we are using the same barcode sealing system as RPM.

*based on availability

* * * * * * APPROVED for use at Fonda Speedway * * * * * *

* * * * * * APPROVED * * * Glen Ridge Motorsports* * * * * *

* * * APPROVED * * * Albany/Saratoga & Devil's Bowl * * *


Still Looking for an Original GM Performance Parts 602 Crate Engine?
